Texas Instruments TPS25984BEVM Evaluation Module

Texas Instruments TPS25984BEVM Evaluation Module provides the necessary requirements to evaluate the reference circuit of the TPS25984B eFuse. The TPS25984B is a 4.5V to 16V, 70A eFuse with an integrated 0.8mΩ FET. The device has overcurrent and inrush current management, an adjustable overcurrent transient blanking timer, and programmable undervoltage and overvoltage protections.

The TI TPS25984BEVM eFuse evaluation board provides options to apply custom load transients using onboard MOSFETs, gate drive circuits, and load resistors.

Features

5V to 16V (typical) operation
14A to 120A programmable circuit breaker threshold using onboard jumpers
Adjustable reference voltage for overcurrent protection and active current-sharing blocks
Fixed transient current blanking timer
Adjustable current limit during start-up and active current sharing threshold using onboard jumpers

Adjustable output voltage slew rate control
TVS diode for input and Schottky diode for output transient protections
LED status for power good and fault indications
Options to engage the power cycle and the quick output discharge (QOD)
Option to apply custom load transients using onboard MOSFETs, gate drive circuit, and load resistors
